ENGINE TYPE686cc liquid-cooled SOHC 4-stroke; 4 valves
BORE X STROKE102.0mm x 84.0mm
COMPRESSION RATIO10.0:1
FUEL DELIVERYYamaha Fuel Injection (YFI)
IGNITIONTCI: Transistor Controlled Ignition
TRANSMISSIONUltramatic V-belt with all-wheel engine braking; L, H, N, R
FINAL DRIVEOn-Command; 3-way locking differential; 2WD, 4WD, locked 4WD; shaft drive
FUEL CAPACITY9.7 gal
SUSPENSION/FRONTIndependent double wishbone; 8.1-in travel
SUSPENSION/REARIndependent double wishbone; 8.1-in travel
BRAKES/FRONTDual hydraulic disc
BRAKES/REARDual hydraulic disc
TIRES/FRONTAT25 x 8-12
TIRES/REARAT25 x 10-12
LXWXH122.1 in x 61.8 in x 75.8 in
WHEELBASE84.1 in
MAX. GROUND CLEARANCE11.8 in
WET WEIGHT1,475 lbs
WARRANTY6 Month (Limited Factory Warranty) – Yamaha 10-Year Belt Warranty
