ENGINE TYPE689cc liquid-cooled, 4-stroke, DOHC inline twin-cylinder; 4-valves per cylinder
BORE X STROKE80.0mm x 68.6mm
COMPRESSION RATIO11.5:1
FUEL DELIVERYFuel injection with YCC-T
IGNITIONTCI: Transistor Controlled Ignition
TRANSMISSION6-speed; wet multiplate clutch
FINAL DRIVEChain
FUEL CAPACITY4.2 gal
SUSPENSION/FRONT43mm inverted fork, fully-adjustable; 8.3-in travel
SUSPENSION/REARSingle shock, adjustable preload (w / remote adjuster) and rebound damping; 7.9-in travel
BRAKES/FRONTDual 282mm hydraulic disc; selectable ABS
BRAKES/REAR245mm hydraulic disc; selectable ABS
TIRES/FRONT90/90R21 Pirelli® Scorpion® Rally STR
TIRES/REAR150/70R18 Pirelli® Scorpion® Rally STR
LXWXH93.3 in x 35.6 in x 57.3 in
SEAT HEIGHT34.4 in
WHEELBASE62.8 in
RAKE (CASTER ANGLE)27°
TRAIL4.1 in
MAX. GROUND CLEARANCE9.4 in
FUEL ECONOMYTBD
WET WEIGHT459 lb
WARRANTY1 Year (Limited Factory Warranty)
