ENGINE TYPE686cc liquid-cooled SOHC 4-stroke
BORE X STROKE102.0mm x 84.0mm
COMPRESSION RATIO10.0:1
FUEL DELIVERYYamaha Fuel Injection (YFI), 44mm
TRANSMISSIONUltramatic V-belt with all-wheel engine braking; H, L, N, R, P
FINAL DRIVEOn-Command 3-way locking differential; 2WD, 4WD, locked 4WD; shaft
FUEL CAPACITY4.8 gal
SUSPENSION/FRONTIndependent double wishbone; 5-way preload adjustment, 7.1-in travel
SUSPENSION/REARIndependent double wishbone with anti-sway bar; 5-way preload adjustment, 9.1-in travel
BRAKES/FRONTDual hydraulic disc
BRAKES/REARMulti-disk wet brake
TIRES/FRONTAT25 x 8-12 Maxxis® MU19
TIRES/REARAT25 x 10-12 Maxxis® MU20
LXWXH81.5 in x 46.5 in x 48.8 in
SEAT HEIGHT33.9 in
WHEELBASE49.2 in
MAX. GROUND CLEARANCE10.8 in
WET WEIGHT686 lb
WARRANTY6 Month (Limited Factory Warranty), 10-Year V-Belt Limited Warranty
