ENGINE TYPE421cc liquid-cooled SOHC 4-stroke; 2 valves
BORE X STROKE84.5mm x 75.0mm
COMPRESSION RATIO10.0:1
FUEL DELIVERYYamaha Fuel Injection (YFI), 34mm
TRANSMISSIONUltramatic V-belt with all-wheel engine braking; H, L, N, R, P
FINAL DRIVEOn-Command selectable 2WD or 4WD; shaft
FUEL CAPACITY3.7 gal
SUSPENSION/FRONTIndependent double wishbone; 6.7-in travel
SUSPENSION/REARIndependent double wishbone; 7.4-in travel
BRAKES/FRONTDual hydraulic disc
BRAKES/REARMulti-disk wet brake
TIRES/FRONTAT25 x 8-12
TIRES/REARAT25 x 10-12
LXWXH80.1 in x 46.5 in x 45.7 in
SEAT HEIGHT33.7 in
WHEELBASE48.8 in
MAX. GROUND CLEARANCE9.6 in
WET WEIGHT637 lb
WARRANTY6 Month (Limited Factory Warranty) – 10-Year V-Belt Limited Warranty
