ENGINE TYPE686cc liquid-cooled SOHC 4-stroke
BORE X STROKE102.0mm x 84.0mm
COMPRESSION RATIO10.0:1
FUEL DELIVERYYamaha Fuel Injection (YFI), 44mm
TRANSMISSIONUltramatic V-belt with all-wheel engine braking; H, L, N, R, P
FINAL DRIVEOn-Command 3-way locking differential; 2WD, 4WD, locked 4WD; shaft
FUEL CAPACITY4.8 gal
SUSPENSION/FRONTIndependent double wishbone; 5-way preload adjustment, 7.6-in travel
SUSPENSION/REARIndependent double wishbone with anti-sway bar; 5-way preload adjustment, 9.1-in travel
BRAKES/FRONTDual hydraulic disc
BRAKES/REARDual hydraulic disc
TIRES/FRONTAT27 x 10-14 Maxxis® 'Zilla MU01
TIRES/REARAT27 x 10-14 Maxxis® 'Zilla MU01
LXWXH81.5 in x 49.2 in x 50.0 in
SEAT HEIGHT36.6 in
WHEELBASE49.2 in
MAX. GROUND CLEARANCE11.8 in
WET WEIGHT783 lb
WARRANTY6 Month (Limited Factory Warranty) – 10-Year V-Belt Limited Warranty
