CFMOTO · Sport SxS · 2026

2026 ZFORCE 800 Trail

50" wide. Trail-legal. 58 hp.

2026 ZFORCE 800 Trail sport sxs from CFMOTO, right-side studio view

What you get

The 50" stance clears restricted trails without compromise. An 800cc V-Twin pushes 58 hp and 50 lb-ft torque through a CVTech CVT with dual power modes, so you dial in control on variable terrain. Electronic power steering, adjustable sport seats, and 10" front / 12" rear wheel travel handle high-speed lines and rough ground. The ZForce 800 Trail carries a 3500 lb winch, full LED lighting, and a 5" digital display. Moon Motorsports stocks them in Monticello.

  • 800 cc displacement
  • 58 hp at 7500 rpm
  • 50 lb-ft peak torque
  • 1290 lbs. dry weight

Full specifications

ENGINE

ENGINE TYPEV-Twin, liquid cooled, 4-stroke, SOHC, 8-valve
DISPLACEMENT800cc
MAX POWER58 HP @ 7500 RPM
MAX TORQUE50 LB-FT @ 5750 RPM
FUEL SYSTEMBosch® EFI
COOLING SYSTEMLiquid cooled
DRIVE2WD/4WD/4WD lock
TRANSMISSIONCVTech® CVT P/R/N/H/L

DIMENSIONS & WEIGHT

LENGTH X WIDTH X HEIGHT121” x 50” x 72”
WHEELBASE90”
DRY WEIGHT1290 lbs
GROUND CLEARANCE10”
FUEL TANK CAPACITY9.8 gal.
TURNING RADIUS15.4'

CHASSIS

SUSPENSIONFront: Dual arched A-arms / Rear: Dual A-arms with adjustable Toe Control Link
WHEELS14” Cast Aluminum
TIRESFront: 26” x 8” x 14” / Rear: 26” x 9” x 14”
SHOCKSSpring preload adjustable, oil damped
BRAKES4-wheel hydraulic disc with parking brake
WHEEL TRAVELFront 10” / Rear 12”

STANDARD EQUIPMENT

HITCH/RECEIVER2”
TOWING CAPACITY1500 lbs.
WINCH3500 lbs.
ADDITIONAL FEATURESElectronic power steering, 3500 lb. winch, electronic throttle with normal/sport modes, LCD display, CFMOTO RideSync app compatible (T-Box), 12V outlet, USB port, LED headlights/taillights with backup lights, roof, fender flares, tilt steering, adjustable driver's seat, half doors, 2” receiver, HDPE skid plate, front bumper, bus bar, front & rear swaybars
COLORSNebula Black, Magma Red
