Can-Am · Sport Side-by-Side · 2026

2026 Can-Am Outlander XT-P 1000R

1000cc power. 12-inch ground clearance. Built for trail and work.

2026 Can-Am Outlander XT-P 1000R sport side-by-side from Can-Am, right-side studio view

What you get

The 1000R engine pushes 1,000 cc of power through a selectable 2WD/4WD drivetrain with three riding modes: Work, Standard, and Sport. FOX Podium QS3 shocks front and rear handle 10.8 and 12 inches of travel. The HD3500 winch with synthetic cable anchors recovery duty. A 10.25-inch touchscreen display keeps you dialed on the trail. Moon Motorsports stocks the 2026 Outlander XT-P 1000R in Monticello.

Full specifications

ENGINE

Engine1000R
Engine displacement1000

DIMENSIONS & CAPACITIES

L x W x H88.4 x 48.5 x 49 in. (224.6 x 123.1 x 124.5 cm)
Ground Clearance12 in. (30.5 cm)
Gauge7.6 in. wide digital display 10.25 in. touchscreen display
WinchCan-Am HD3500 (1,588 kg) winch with synthetic cable
ProtectionFull skid plate, Heavy Duty front and rear bumpers, Handguards
Type of gauge7.6 in. wide digital display 10.25 in. touchscreen display

SUSPENSION & BRAKES

FrontOVERSIZED Dual 252 mm disc brakes with hydraulic twin-piston calipers
RearDual 214 mm disc brakes with hydraulic twin-piston calipers
BrakesStandard
Front SuspensionArched Double A-arm with sway bar 10.8 in. (27.4 cm) travel
Front ShocksPiggyback FOX Podium QS3 Gas shocks
Rear SuspensionArched Double A-arm 12 in. (30.5 cm) travel
Rear ShocksPiggyback FOX Podium QS3 Gaz shocks

DRIVETRAIN

TransmissionpDrive primary CVT with specific calibration L / H / N / R / P
Drive TrainSelectable 2WD / 4WD / Lock 4WD with Visco-4Lok front differential
Driving AssistanceWork / Standard / Sport modes Intelligent Engine Braking (iEBâ„¢)
Front TiresXPS Trail King 2 – 27 x 8/10 x 14 in.
Rear TiresXPS Trail King 2 – 27 x 8/10 x 14 in.
